Bill's Azimuthal Projection Image Creation Tool

This site allows you to create an Azimuthal Projection of the world centered around any location you choose. An Azimuthal Projection is a map projection in which the entire earth's surface or a region of it is projected onto a plane tangential to the surface. There are 2 main types of these projections:

Azimuthal Equidistant Projection - which has the properties that all points on the map are at proportionally correct distances from the center point, and that all points are at the correct azimuth from the center point.

Azimuthal Equal Area Projection - which projects the Earth's surface onto a flat plane from a central point, preserving true area and direction from the center, but distorting shape and scale.

Input information

1. Choose an initial Equirectangular Projection image as a reference for the Azimuthal Projection:

2000x1000

4096x2048

4424x2214

8192x4096

10000x5000

2. Choose a town or city for the center of the plot:

or manually enter Latitude: and Longitude:

3. Choose a projection type: Azimuthal Equidistant Azimuthal Equal Area

Output options

Show lat and long lines. Interval: degrees Color:

Show distance lines. Interval: Color:

Town Label Options

Font: Size: px Color:

Draft Image

Final image size: px
